Product Overview

  • The MK1-BXL finger pinch protector guard for door hinges is installed on the hinge-pin or pull-side of the door. It is double the width of our original MK1-B to accommodate XL barrel hinges.
  • Retrofitted using screws or 3-M adhesive tape (supplied on request) for glass doors.
  • Stock size is 96″ color: Grey, Black and White
  • Can be easily cut to size on site
  • As with all Fingersafe products, this hinge guard protects fingers from the full length of the door.
  • Can be installed as a sight guard in bathroom and medical facilities.
  • Can be installed on interior or exterior doors.
  • Can be easily cut on site to accommodate any door or gate.
  • Compliant for commercial applications and has a 4-hour fire door rating.
  • Constructed of high-quality PVC (UL V-O rated) with TPE hinges. They have a high impact resistance and are easily cleaned with common household cleaners.
  • Durability: U.V. and high impact resistance. Easily cleaned.

Made from PVC-U and TPE, it isĀ  weatherproof, resistant to UV and acts as a draft excluder and smoke inhibitor.

Click >>HERE<< for Specification Sheet

Product Details




A unique, inconspicuous and easy to install finger pinch protector guard for door hinges designed to prevent fingers being trapped in opening and closing doors.


With some 300,000 reported incidents of amputated, mutilated or damaged fingers in doors per year, Fingersafe is designed specifically to prevent fingers from being damaged in the hinged end of doors. Besides the cost in trauma, treatment and disability, the owner or manager of a facility could be held responsible and incur litigation for personal injury. Having identified the need in the market, Fingersafe was developed as the original finger pinch protector guard for door hinges. Since 1996, Fingersafe has closed the door on injuries in the US.

Fingersafe Finger Pinch Protector Guards for Door Hinges Applications

Fingersafe is compatible with all types of standard hinged doors including: fire doors, wood, metal, aluminum, YKK type openings and dutch doors. Resistant to UV light, Fingersafe is designed for interior or exterior use. Specific uses include schools and other educational facilities, childcare and healthcare centers, homes for the elderly and infirm as well as residential use. It is commercially specified for restaurants, fast food outlets, as well as government and military buildings.

Fingersafe Finger Pinch Protector Guards for Door Hinges Description

Fingersafe offers no resistance or restriction to the door operation and allows over 180 degrees of operation. It protects the full length of the door on each side of the hinged end of door. The MKl-A is a flexible, accordion shaped fitting designed to actually eject fingers from being trapped or crushed in the “push” side of doors. When the door is closed the fitting is compressed, but when the door is opened the fitting extends and provides a protective covering over the hinged end space. The accordion piece lies flat against the frame when the door is closed for aesthetically pleasing design. MKl-A units are installed via a fixing strip which allows easy access to the hinge
for maintenance.

Materials and Finishes

Made in the USA. PVC (UL V-0 rated) with TPE hinges designed for commercial use. Dimensions Stock lengths are 96 inches Appearance Available in White (default), Black, and Grey at no extra cost


Unlike an inferior finger shield or wrap around device, Fingersafe MK1-B XL allows even a fire door to open to 180 degrees . It also offers draft
exclusion and is a smoke inhibitor.


Fingersafe is compatible with all types of doors.


Fingersafe is resistant to most household chemicals such as bleach, alcohol and other multi surface disinfectants and may be cleaned with any readily available cleaning products.


Simple to install in minutes. Retrofitted to existing doors using self tapping screws and installation accessories are included. See our installation page for further details.

Availability and Cost

Fingersafe products are stocked in 96″ with a one week turn around. A two year warranty is offered on fair wear and tear, supply only. Samples may be supplied on request to a potential client for evaluation purposes.

Click >>HERE<< for Specification Sheet

Additional information

Additional information

Weight 2 lbs
Dimensions 84 × 1 × 1 in

White, Grey, Black
